Aluminum foil 7mic
Pet Thickness:4.5-125u
Width : 5mm-1000mm ID : 76 ±0.5mm or 105 ±0.5mm OD : 250mm-650mm
Color : silver
Tensile Strength, Mpa ≥50
Banding Elongation,% ≥15
Bond Strength ,N/cm ≥ 4
Characteristic
Eco-friendly, water repellent. It can have anti-UV(1%-5%), anti-bacteria, anti-static, flame retardant function as request. Tear resistant, shrink-resistant. Strong strength and elongation, soft, non-toxic. Excellent property of air through
Application
Used for produce insulated aluminum foil flexible ducts sleeves , un-insulated aluminum foil flexible ducts .
|
Structure |
Thickness(um) |
Proportion(g/m2) |
Elongation(%) |
Strength(N/15mm) |
|
6um AL/12um PET |
20 |
36 |
30 |
2.7 |
|
7um AL/15um PET |
25 |
43 |
35 |
2.7 |
|
7um AL/20um PET |
30 |
50 |
35 |
3 |
|
9um AL/12um PET |
25 |
45 |
30 |
2.7 |
|
9um AL/15um PET |
30 |
49 |
35 |
3 |
|
9um AL/20um PET |
35 |
55 |
35 |
3 |
|
9um AL/25um PET |
38 |
62 |
35 |
4 |
|
12um AL/12um PET |
25 |
53 |
20 |
2 |
|
12um AL/15um PET |
30 |
57 |
20 |
3 |
|
12um AL/20um PET |
35 |
63 |
30 |
4 |
|
15um AL/15um PET |
30 |
65 |
20 |
3 |
|
25um AL/15um PET |
45 |
92 |
20 |
3 |
|
30um AL/25um PET |
60 |
119 |
20 |
3 |
|
30um AL/30um PET |
65 |
126 |
20 |
5 |
|
40um AL/30um PET |
75 |
153 |
20 |
5 |
|
40um AL/38um PET |
80 |
163 |
20 |
5 |
|
50um AL/25um PET |
90 |
173 |
20 |
5 |
|
50um AL/50um PET |
100 |
207 |
35 |
6 |
